Slip tester
The Standard Portable Slip Resistance Tester
- High Quality KSS Pendulum Tester
- Durable Black Carry Case with Wheels
- Tool Roll Holder with 1x 17mm Spanner, 1x Brush, 1x C-Hook Wrench, 1x Allen Key Set, 1x KSS Setting Gauge and 1x Spray Bottle.
- Pavigres Tile
- Calibration Sheets ( Pink Lapping Film and 400 Grit Wet & Dry Paper)
- Calibration Certificate & Rubber Conformity Certificate
- 4x Sliders of Your Choice ( Slider 55, Slider 96 or Slider CEN)
- *The First Recalibration Free of Charge, if Returned to KSS Factory Within 12 Months of Purchase
- Free Training at Our Factory, for up to 2 People.
*if Purchased directly from KSS AND NOT AT DISCOUNTED RATE
Deluxe Slip Tester
- High Quality KSS Pendulum Tester
- Durable Black Carry Case with Wheels
- Tool Roll Holder with 1x 17mm Spanner, 1x Brush, 1x C-Hook Wrench, 1x Allen Key Set, 1x KSS Setting Gauge and 1x Spray Bottle.
- Aluminium Sample Holder
- Float Glass
- Pavigres Tile
- Calibration Sheets ( Pink Lapping Film and 400 Grit Wet & Dry Paper)
- Calibration Certificate, Rubber and Tile Conformity Certificates
- 4x Sliders of Your Choice ( Slider 55, Slider 96 or Slider CEN)
- *The First Recalibration Free of Charge, if Returned to KSS Factory Within 12 Months of Purchase
- Free Training at Our Factory, for up to 4 People.
*if Purchased directly from KSS AND NOT AT DISCOUNTED RATE
The benefits of purchasing this KSS Pendulum Kit:
- Free training at our factory, training up to 4 people
- Compact and easy to transport
- Can be used in remote locations
- Enclosed bearings and working parts for protection against wear
- Heavy-duty frame
- Fully adjustable feet for accuracy
How Does It Work?
The Pendulum measures the frictional resistance between a rubber slider mounted on the end of a pendulum arm and the test surface.
This provides highway and flooring engineers with a routine method of checking the resistance of wet and dry surfaces to slipping and skidding.
The Pendulum device is placed on the portion of the road/ floor surface to be tested. It is then levelled and the height of the centre of suspension of the pendulum is adjusted to a fixed value which is read on a special gauge.
The Pendulum arm has a spring-loaded rubber slider on the pendulum foot.
The Pendulum is then released from its horizontal position, to swing down freely until the rubber slider contacts the test surface.
As the slider travels across the surface for a fixed distance, the pendulum is slowed and a frictionally-constrained pointer affixed to the pendulum arm measures the highest point in the pendulum arc.
The position of the pointer is then read on a measuring arc graduated from 0 to 150.
Pointer readings indicate the resistance to skidding/slipping of the test surface.
All this will be explained in our Training and much more
Applications for the Pendulum
The Pendulum is established globally as an essential part of risk management policies in the following areas:
- Testing of floors and pedestrian walkways
- Flooring materials product development
- Accident investigations, both traffic and pedestrian
- Litigation investigations
- Road surface testing
- Testing of new road surface materials under development
- Testing of aggregates in the PSV (polished stone value) test
- Testing of pavers in the Flat Bed Polisher
It is used in the following ways:
- Assessing surface safety
- Evaluation of floor cleaning materials
- Checking the effectiveness of maintenance and cleaning procedures
- Accident investigations
- Evidence for litigation purposes
Other Useful Infomation
- Dimensions of Carry case 75cm x 74cm x 35cm
- Shipping Weight 32kg
